ROG MAXIMUS Z690 FORMULA
Intel® Z690 ATX motherboard with 20+1 power stages, DDR5, Five M.2, USB 3.2 Gen 2x2 front-panel connector, Dual Thunderbolt™ 4, PCIe® 5.0, Onboard WiFi 6E, 10 Gb Ethernet and Aura Sync RGB lighting
- Intel® LGA 1700 socket: Ready for 13th Gen Intel® Core™ Processors and 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors
- Intelligent Control: ASUS-exclusive tools including AI Overclocking, AI Cooling, AI Networking and Two-Way AI Noise Cancelation for easy configuration
- Robust Power Solution: 20+1 teamed power stages rated for 105 A, ProCool II power connectors, MicroFine alloy chokes and premium metallic capacitors
- Optimized Thermal Design: Enlarged VRM heatsinks with EK CrossChill III solution, high-conductivity thermal pads, triple M.2 heatsinks and two M.2 backplates, and ROG Water-Cooling Zone
- High-Performance Networking: Onboard WiFi 6E, Marvell® AQtion 10 Gb Ethernet, and ASUS LANGaurd
- Fastest Connectivity: PCIe® 5.0, dual Gen 4 M.2 onboard, ROG Hyper M.2 card with Gen 5 M.2 support, USB 3.2 Gen 2x2 front-panel connector and dual Thunderbolt™ 4 USB Type-C® ports
- Industry-Leading Audio: ROG SupremeFX ALC4082 with ESS® ES9018Q2C DAC for pinpoint positioning and dynamics
- Unmatched Personalization: 2-inch LiveDash OLED, ASUS-exclusive Aura Sync RGB lighting, including one RGB header and three addressable Gen 2 headers
- DIY-Friendly Design: Pre-mounted I/O shield, PCIe Slot Q-Release, Q-Latch, BIOS FlashBack™, Q-Code, FlexKey, Q-Connector, SafeSlot, ROG Hyper M.2 card, and ROG graphics card holder
- Renowned Software: Bundled 1year AIDA64 Extreme subscription and intuitive UEFI BIOS dashboard with integrated MemTest86
Awards
Video Reviews
Video review from the channel HDTanel. Rating 10/10
Video review from the channel Konsumer
The new ROG Z690 Formula is just purely gorgeous, with its white and silver theme covering most of the board.
ASUS is traditionally well represented in the high-end segment.
相変わらずハプニングは絶えませんが『究極のハイスペ白PC』が完成しました。💎i9 12900K＋RTX3080💎
Super terrible game corner - when money is no longer a problem !!! - ROG MAXIMUS Z690 FORMULA
#Buildpc - How rich and rich people - Beautiful is okay - ROG MAXIMUS Z690 FORMULA
This PC is united for any game !!!
Nothing to heat this PC | PC full custom cooling | ROG MAXIMUS Z690 FORMULA
PC Timelapse i9-12900KS & RTX 3090 | GVN Titan Plus i3090 | ROG MAXIMUS Z690 FORMULA
How powerful is INTEL I9-12900KS??!! FULL PC SETUP BEST CONFIGURATION
Everything about performance, storage, gaming, professional is here
We're building a new high end PC into ROG Hyperion!
Video review from the channel TheTanelChannel. Rating 10/10
Video review from the channel Konsumer
Media Reviews
Formula
ROG Maximus Z690 Formula
Diversity to the Maximus. That’s what the latest Formula brings to the acclaimed ROG Maximus series. Its Moonlight White armor and customizable ARGB lighting elements ride alongside a hybrid VRM block designed in collaboration with EK, giving you ample freedom to express your preferred build style. And underneath, circuit pathways illuminated with PCIe® Gen 5.0 and limit-breaking DDR5 support are poised to elevate performance well into the future, driving the Maximus Z690 Formula's appeal far beyond aesthetics.
Intelligent Motherboard
Intelligent software solutions help ensure that your system performs at its best. The latest ASUS AI-powered enhancements span four pillars of performance, including overclocking, cooling, networking and onboard audio, making advanced tweaks and optimization accessible to new recruits and savvy PC DIY veterans alike.
AI Overclocking
Tuning is now faster and smarter than ever before. ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push each system to its limits.
LEARN MOREAI Cooling
Balance the thermals and acoustics of any build with a single click. A proprietary ASUS algorithm reduces unnecessary system noise by monitoring CPU temperatures and dynamically adjusting fans to optimal speeds.
LEARN MOREAI Networking
GameFirst VI optimizes networking performance by allocating bandwidth in real time based on application usage scenarios and corresponding learning algorithms.
LEARN MORETwo-Way AI Noise Cancelation
This utility leverages a massive deep-learning database to reduce over 500 million types of background noise from incoming or outgoing audio, helping ensure crystal-clear communication in games or calls.
LEARN MORESPEC OVERVIEW
- Performance
- Cooling
- Gaming Immersion
- Connectivity
- DIY friendly
Extreme Power & Performance
- PROCOOL II POWER CONNECTORS
- 20 + 1 POWER STAGES
-
EXPANSION SLOTS
・ 2 x PCIe 5.0 x16 slots (x16, x8/x8)
・ 1 x PCIe 4.0 x16 slot (x4, x4/x4 via ROG Hyper M.2 card)
- INTEL® LGA 1700 SOCKET FOR 13TH GEN INTEL® CORE™ PROCESSORS AND 12TH GEN INTEL® CORE™, PENTIUM® GOLD, AND CELERON® PROCESSORS
-
DDR5, 4 X DIMM
・ Dual Channel
-
3 X M.2 SLOTS
・ 1 x M.2 2242~22110 supports PCIe 4.0 x4 mode
・ 1 x M.2 2242~2280 supports PCIe 4.0 x4 & SATA modes
・ 1 x M.2 2242~2280 supports PCIe 3.0 x4 mode
2 X M.2 SLOTS VIA ROG HYPER M.2 CARD・ 1 x M.2 2242~22110 supports PCIe 5.0 x4 mode
or
・ 2 x M.2 2242~22110 support PCIe 4.0 x4 mode
Comprehensive Cooling
- MOONLIGHT-WHITE METAL COVER CROSSCHILL EK III
-
TRIPLE M.2 HEATSINKS
DUAL M.2 BACKPLATES
BUNDLED ROG HYPER M.2 CARD WITH M.2 HEATSINKS AND THERMAL PADS
-
MULTIPLE 4-PIN PWM FAN HEADERS
・ CHA_FAN1P-3P headers support ASUS HYDRANODE
-
ROG WATER-COOLING ZONE
・ W_FLOW tachometer
・ W_IN/OUT T-sensor
Total Gaming Immersion
-
I/O ZONE AURA LIGHTING
AURA Lighting
-
SUPREMEFX AUDIO CODEC ALC4082®
・ ESS® SABRE9018Q2C high-definition DAC
・ 120 dB SNR stereo playback output
・ 113 dB SNR recording input
・ Gold-plated audio jacks
SONIC STUDIO III + SONIC STUDIO VIRTUAL MIXER + SONIC SUITE COMPANION SONIC RADAR III DTS® SOUND UNBOUND - LIVEDASH OLED 2”
- CHIPSET ZONE AURA LIGHTING
-
3 X 3-PIN ADDRESSABLE GEN 2 HEADERS
1 X 4-PIN AURA RGB HEADER
Full Connectivity
- BIOS FLASHBACK™ BUTTON
- CLEAR CMOS BUTTON
- 1 x HDMI® PORT
- 3 x USB 2.0 PORTS
- 2 X THUNDERBOLT™ 4 USB TYPE-C® PORTS
- 1 X MARVELL® 10GB ETHERNET PORT
- 7 X USB 3.2 GEN 2 PORTS (6 X TYPE-A + 1 X USB TYPE-C®)
- 1 X WIFI 6E MODULE
- OPTICAL S/PDIF OUT
- 5 X GOLD-PLATED AUDIO JACKS
-
1 X USB 3.2 GEN 2X2
USB Type-C® front panel connector supports QC4+
- 4 X USB 3.2 GEN 1
- 6 X SATA 6GB/S
DIY Friendly
- ROG PATENTED PRE-MOUNTED I/O SHIELD
-
ESD GUARDS
Provides greater electrostatic protection than the industry standard. ESD Guards cover the USB, audio and LAN ports.
-
TRUEVOLT USB
Supplies stable 5-volt power delivery to all USB ports, with minimal power fluctuations to minimize data loss.
-
LIVEDASH OLED 2”
Indicates power status and potential problems with the CPU, memory, graphics card or boot device for quick diagnosis.
-
2 X SAFESLOTS
Provides stronger PCIe device retention and greater shearing resistance.
-
ASUS HYDRANODE
The three chassis fan headers feature the ASUS HYDRANODE circuit, which utilizes a powerline communication protocol to control up to three daisy chained fans independently through each 4-pin connector.
-
Q-CODE
LED panel shows a 2-digit code to reflect system status.
-
4 x Q-DIMM
One sided clips for super-simple, super-secure handling of memory modules.
-
FLEXKEY
At its default, the FlexKey functions as a system reset button, but it can also be easily set to quickly turn Aura lighting on or off, activate Safe Boot or enter the BIOS.
-
PCIE SLOT Q-RELEASE
A physical button unlocks the first PCIe slot’s security latch with one tap, greatly simplifying the process of detaching a PCIe card from the motherboard when it’s time to upgrade to a new GPU or other compatible device.
-
M.2 Q-LATCH
The innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the drive and neatly eliminate traditional screws.
-
Q-CONNECTOR
Simple adapter that helps arrange front-panel cables in an orderly manner.
SPEC OVERVIEW
- Power Solution
- Memory
PERFORMANCE
The ROG Maximus Z690 Formula CPU VRM is comprised of 105 amp power stages that are strategically teamed to quickly cancel transients. Alongside, the ROG take on DDR5 support frees memory kits to achieve their full potential.
Teamed power architecture
Modern CPU architectures up the ante for motherboard power design by transitioning from deep power saving modes to full load almost instantaneously. The latest ROG VRM architecture rises to the challenge by utilizing teamed power stages to rapidly swing current, while maintaining exemplary thermal.
- A brief history
- A shift in CPU demands
- Bucking the trend
- Thermal performance
- High-quality components
Teamed
Power Stage Design
12V EPS IN
12V EPS IN
Conventional
Phase-doubled Design
12V EPS IN
12V EPS IN
-
ASUS became the first manufacturer to implement phase doublers when we shipped the A8N32-SLI Deluxe back in 2005. The board’s VRM was lauded for elegantly overcoming the power handling capabilities of components that were available at the time while also reducing voltage ripple. Those benefits lead to phase doublers becoming universally accepted in the industry, and they are still used for similar purposes today.
-
Today’s CPUs pack more cores than their predecessors, and the latest instruction sets allow them to crunch computationally dense workloads at an incredible pace. As an added bonus, these processors also consume less power at idle and can transition between loads states much more quickly. These improvements necessitated a re-evaluation of power design priorities, because phase doublers add a propagation delay that hampers transient response.
-
The latest integrated power components can handle higher currents than the devices of yesteryear, making it possible to implement a simple circuit topology that isn’t hamstrung by the processing lag of phase doublers. That’s why the ROG Maximus Z690 Formula utilizes teamed power stages to deliver higher burst current per phase, while maintaining the thermal performance of phase-doubled designs.
-
Each VRM component serves a specific purpose. PWM controllers control the circuit, and the power stages do the heavy lifting from an electrical and thermal standpoint. That's why ROG Maximus Z690 Formula utilizes 20 power stages. The high-end power stages feature a low RDSON to reduce switching and conduction losses, helping to improve overall thermal headroom.
-
8+8 pin ProCool II power connectors
Two ProCool connectors ensure a snug and reliable connection to the EPS 12V power lines.
-
20+1 power stages
The VRM features 20+1 power stages, each rated to handle 105 amps.
-
MicroFine alloy chokes
Each power stage is accompanied by a high-permeability alloy-core choke rated to handle 45 amps.
-
10K black metallic capacitors
Input and output filtering is provided by solid-polymer capacitors rated to last thousands of hours at high operating temperatures.
DDR5 Overclocking strength
Comprehensive memory tuning options are the cornerstone of ROG motherboards. For DDR5, the Maximus Z690 lineup breaks performance limits by providing a stacked suite of overclocking parameters for not only high-speed kits, but even entry-level memory modules that have a locked power management IC (PMIC).
- A dedicated circuit on the motherboard safely circumvents DDR5 memory PMIC restrictions, allowing you to step past the default 1.1-volt limit and push frequency and timings to the max.
- Ordinarily, a restricted PMIC that has been unlocked requires the system to be fully power-cycled each time memory voltage is adjusted. ROG motherboards leverage onboard hardware and firmware to cleverly work around this irksome limitation, enabling voltage adjustments to be applied through the same soft system-reset process employed for previous generations of DDR memory.
ASUS Enhanced Memory Profile (AEMP) is an exclusive firmware feature for PMIC-restricted memory modules. AEMP automatically detects the memory chips on your kit and then presents optimized frequency, timing and voltage profiles that you can effortlessly apply to unleash performance.
- Crosschill ek III
- Heatsinks
- Headers
COOLING
An ambition to maximize performance calls for an appropriately powerful platform. Enter the CrossChill EK III VRM block, empowering enthusiasts to break the limits of conventional voltage regulation with a hybrid cooling system that sails past the core power requirements of 12th Gen Intel Core processors while maintaining rock-steady thermals.
Crosschill EK III
The CrossChill EK III water block leverages a fusion of passive and liquid cooling to keep VRMs operating at high efficiency. The nickel water channel hidden within the block quietly cools the Formula’s MOSFETs up to 63.7°C more than air alone, while the standard G1/4" threaded fittings are designed to integrate into existing setups with minimal effort.
- Metal cover
- G1/4" threaded design
- Watertight rubber gasket
- Nickel water channel
- Large nickel surface area
Cooler by Design
-
CrossChill hybrid
thermal designEngineered with a nickel cooling channel that's incredibly effective at removing heat.
-
M.2 backplates
Dual M.2 slots feature backplate blocks that ensure high-performance drives deliver peak performance, even when airflow is restricted.
-
M.2 heatsinks
Three dedicated heatsinks keep up to three M.2 drives in the optimum operating temperature range for consistent performance and reliability.
-
High-conductivity thermal pad
A high-quality thermal pad improves overall heat transfer from the system by bridging the heat generated by the power stages to the heatsink.
-
Solid steel backplate
An electro-galvanized, cold-rolled coil construction backplate resists bending and helps draw heat away from the VRM.
-
Chipset heatsink
A dedicated chipset heatsink draws heat away to maintain optimum operating temperatures.
- Thermal Management
- ROG Water-Cooling Zone
- Thermal management
- ROG Water-Cooling Zone
Thermal management
ROG Maximus Z690 Formula features comprehensive cooling options that are configurable via Fan Xpert 4 or the UEFI BIOS.
- Multiple temperature sources
- 4-pin PWM/DC fan headers and ASUS HYDRANODE
- Bundled ROG fan controller
-
Each header can be set to monitor and react to three user-configurable thermal sensors for workload-based cooling, and all settings can be easily managed by Fan Xpert 4 or via the UEFI.
-
Every onboard header auto-detects any PWM or DC fan, with three chassis fan headers offering ASUS HYDRANODE support.
-
A bundled fan controller card includes six additional DC and PWM fan headers, plus two thermal-probe headers.
ROG Water-Cooling Zone
Dual water-temperature headers and a flow-rate header feed information straight into the AI Suite utility, allowing you to track coolant temperatures and the flow rate of the entire loop.
- Water pump+
- Water in/out
- Water flow
A dedicated header can supply over 3 amps to a high-performance PWM or DC water pumps.
A dedicated header enables monitoring of temperatures at the input/output points of any component.
A dedicated header enables constant monitoring of flow rate throughout the entire loop.
- Networking
- USB Ports
- Storage
- Audio
CONNECTIVITY
The latest connectivity solutions ― WiFi 6E, PCIe® 5.0 and two Thunderbolt™ 4 USB Type-C® ports ― empower supersmooth networking and blisteringly fast file transfers. And for enthusiasts looking for high-fidelity audio, the SupremeFX ALC4082 codec takes gaming immersion to a whole new level while also saving a PCIe slot.
-
WiFi 6E
Onboard WiFi 6E technology takes advantage of the newly available radio spectrum in the 6 GHz band, providing up to three times the bandwidth of the 5 GHz band and up to seven 160 MHz bands to deliver ultrafast wireless networking speeds along with improved capacity and better performance in dense wireless environments.
-
Marvell® AQtion 10 Gbps Ethernet
Designed to meet the demanding requirements of power users and content creators, 10 Gbps onboard Ethernet provides a new level of home networking. With up to 10 times the bandwidth of standard gigabit Ethernet, you'll enjoy streaming uncompressed 4K UHD videos and system backups and file transfers that are faster than ever before.
-
WiFi 6E antenna
The antenna has two built-in transmitters and receivers to enable faster transmission speeds, and it supports the 2.4, 5 and 6 GHz bands.
-
Adjustable design
Four-way positioning enables better signal reception.
-
Magnetic base
A powerful magnetic base secures the antenna on the top or side of the PC case.
-
USB 3.2 Gen 2x2 Type-C® Front-Panel Connector with Quick Charge 4+
USB 3.2 Gen 2x2 adds an additional lane that can boost Type-C data transfers with speeds of up to 20 Gbps. The port also features Quick Charge 4+ technology that can quickly charge devices up to 60 W with a PCIe power supply cable plugged into the nearby 6-pin connector.
-
Two onboard Thunderbolt 4 USB
Type-C® portsEach port delivers up to 40 Gbps of bidirectional bandwidth for the latest high-speed devices and drives. Thunderbolt 4 also supports up to two external 4K displays and extends PCIe bandwidth to up to 32 Gbps.
-
Three Onboard M.2 slots
ROG Maximus Z690 Formula features three onboard M.2 slots, with two offering support for PCIe 4.0 SSDs.
-
ROG Hyper M.2 Card
PCIe 5.0 readyIf users need more M.2 storage or even faster data transfers, the bundled ROG Hyper M.2 Card features two more slots, one of which is a PCIe 5.0 and ready to perform at up to twice the speed of the accompanying PCIe 4.0 slot.
SupremeFX
ROG SupremeFX audio technology delivers an exceptional 113 dB signal-to-noise ratio on the line-in connection to provide best-ever recording quality. There's also a low-dropout regulator for clean power delivery to the SupremeFX ALC4082 codec, and an ESS® 9018Q2C integrated DAC.
››› Learn more about ROG audio technology
- Audio line shielding
- ESS® SABRE 9018Q2C
- ALC 4082 Codec
- Switching MOSFETs
- Premium capacitors
-
Blocks electromagnetic interference from the motherboard or add-ons to provide cleaner audio.
-
The ESS® SABRE 9018Q2C integrated DAC amplifier is capable of providing -115 dB total harmonic distortion (THD+N) for playback that conveys all the subtlety and nuances of the audio track. In addition, the 121 dB dynamic range (DNR) provides an extremely low noise-floor, further accentuating dynamics and punch.
-
The ALC4082 codec uses USB instead of the conventional high-definition audio (HDA) interface and improves playback audio resolution from 192 to 384 kHz.
-
A unique design allows the codec's impedance-sensing function to be ported with either the front or rear headphone outputs.
-
High-quality integrated components help produce warm, natural-sounding audio with exceptional clarity.
- 5-Way Optimization
- BIOS
- Differential Sensing
OPTIMIZATION
ROG Maximus Z690 Formula is packed with intuitive and flexible tools that give builders next-level control of system performance.
Level Up Performance
The dashboard-style control panels of AI Suite 3 and Armoury Crate let you fine-tune almost every aspect of your ROG Maximus Z690 Formula system with ease. Get the best balance between performance, cooling, stability, and efficiency via simple and intuitive interfaces.
- TPU
- EPU
- Fan Xpert 4
- Digital power controls
- Turbo Core app
CPU performance boost
The TurboV Processing Unit (TPU) is an intelligent onboard micro-controller that provides an array of system-tuning features, including the ability to fine-tune voltages, monitor system stats and adjust overclocking parameters.
All-around energy efficiency
With the Energy Processing Unit (EPU) you’ll enjoy system-wide power savings. The EPU automactically optimizes power consumption and maximizes savings with Away mode.
Flexible cooling controls for air or liquid
Enjoy comprehensive control over fans, water pumps and all-in-one (AIO) coolers via either Fan Expert 4 or the ASUS UEFI. Whether you're cooling with air or water, Auto-Tuning mode intelligently configures all parameters with a single click. There's also an Extreme Quiet mode, which reduces all fan speeds to below the default minimum — keeping your system whisper-quiet when performing light tasks.
Precise digital power controls
The Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop, switching frequency and power-efficiency settings, allowing you to fine-tune CPU voltage regulation for ultimate stability and performance.
Turbo Core App
Intel processors feature per-core tuning, and the ASUS Turbo app makes use of this feature by letting you assign applications to specific processor cores, prioritizing computing power where it's needed most.
UEFI BIOS
The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans.
- Advanced mode
- EZ mode
MemTest86
For added convenience, MemTest86 has been pre-installed into ROG UEFI (BIOS). Run the test to pinpoint memory issues with just one click, without the need for any USB stick or going into the OS. The memory report will also be stored in the BIOS archives for reference.
When you’re ready for a deeper dive, delve into the UEFI’s Advanced Mode and take complete control. This mode enables full control over every aspect of the motherboard, and a built-in search function helps you quickly find the setting you need.
Advanced mode
-
MemTest86 Learn more
Diagnose faulty RAM and memory problems that can lead to crashes or data issues.
-
My Favorites
Quickly locate tuning options and add preferred tools to your favorites list.
-
EZ Flash 3
Flash the latest BIOS via the internet from within the BIOS.
-
S.M.A.R.T.
Check your storage device Self-Monitoring, Analysis, and Reporting Technology (S.M.A.R.T.) logs to gauge reliability or to identify potential failures.
-
GPU POST
Automatically detect select ASUS graphics cards to view detailed information.
-
Secure Erase
Restore your SSDs and NVMe storage to factory settings.
-
Last Modified Log
Track the last change and save preferred profiles to a USB drive.
-
SATA Port Renaming
Rename SATA ports for easy identification.
-
ASUS User Profile
Port configuration settings between different BIOS versions or share them with friends.
-
Q-Fan Control
Configure the fan's operating speed manually or use pre-configured Standard, Silent, Turbo or Full Speed modes. By default, system fans will automatically switch to full speed if the temperature reaches 75° C.
Designed to simplify setup, EZ Mode presents vital settings and stats on a single page. With guided wizards, drag-and-drop functionality, and one-click application of important settings, your rig will be up and running in no time.
EZ mode
-
Intuitive graphical fan controls
Fine-tune individual fans simply by dragging a curve with the mouse.
-
Storage information
View SATA port details for easy device recognition.
-
Fast and easy clock adjustment
Use the mouse to quickly change time and date settings.
-
Aura on/off mode (Stealth)
Easily enable or disable Aura RGB lighting or every onboard LED for a more subdued aesthetic.
Accurate voltage monitoring
Conventional motherboards use single-ended sensing tapped from a location that isn't ideal, leading to a large disparity between the actual voltage fed to the CPU and the value reported to software. ROG Maximus Z690 Formula features a differential-sensing circuit that simplify overclocking and tuning by allowing you to track voltages more accurately.
- Aura Sync
- LiveDash OLED
- Gaming Audio
- Armoury Crate
- AIDA64 Extreme
- Graphics Card Holder
PERSONALIZATION
ASUS-exclusive Aura Sync RGB customization takes the Formula’s Moonlight White colorway to a new level, and a two-inch OLED LiveDash can take the aesthetic further with a display featuring live system information or user-customizable graphics.
Grow your gaming world
Gear up with ROG components — from graphics card and monitors to mice and keyboards. And up your game with complementary aesthetics, control and compatibility. The ROG ecosystem is more extensive than any competing brand, so you’ll enjoy greater choice as your system expands.
- Static
- Breathing
- Strobing
- Rainbow
- Color cycle
- Starry night
- Music effect
- Smart
- Adaptive color
- Dark
Addressable Gen 2 RGB header
The addressable Gen 2 RGB headers can be controlled with Aura software, which automatically tailors your preferred lighting effects to the number of LEDs present in the connected gear or strip. The new headers also offer backward-compatibility with existing Aura RGB components.
LiveDash OLED
The ROG Maximus Z690 Formula includes LiveDash, a built-in 2-inch OLED panel that shows useful information and features customizable graphics. During the power-on, self-test (POST) phase, the OLED shows key stats in simple language using traditional POST codes. In normal operation, the panel can be programmed to show CPU frequency, device temperatures, fan speeds or water-cooling information. You can also personalize the default OLED GIF with a preferred image or animation.
- Hardware Monitor
- Formula Exclusive
- BIOS Update
- Customization Content
- Sonic Studio III
- DTS : SOUND UNBOUND
Sonic Studio III
Sonic Studio supports HRTF-based (head-related transfer function*) virtual surround for headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options and one-click presets, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset.
*A head-related transfer function is an audio algorithm derived from sound data recorded through a dummy head. Test tones are played from a spherical grid around the dummy head to obtain subtle changes in sounds that come from different directions. The results are combined into an algorithm that allows Sonic Studio's virtual surround to process sound true to life.
- Sonic Studio link
- App-specific profiles
- Sonic Studio virtual mixer
Sonic Studio link
Easily apply Sonic Studio effects on all playback devices. Simply press the Sonic Studio Link button to enjoy the effect on any playback device.
App-specific profiles
Apply customized audio settings to different applications, so everything you do is perfectly tuned to the way you want to listen.
Sonic Studio virtual mixer
Combine audio output from selected apps with audio from the microphone input and stream the compiled mix.
DTS : Sound Unbound
The ROG Maximus Z690 Formula includes a pre-loaded DTS® Sound Unbound™ app that envelops you in audio as never before, conjuring whole new levels of immersion for extraordinary gaming and entertainment experiences. By exploiting Windows Sonic spatial technology, DTS Sound Unbound delivers audio in a virtual 3D space — putting you right in the middle of the soundscape, where you can sense the location and direction of every gunshot, footstep or other sound in your virtual environment.
* DTS Sound Unbound requires in-game support. Check with developers for titles that offer support.
-
Stereo Sound
-
Surround Sound
-
Spatial Sound
Armoury Crate
Armoury Crate is a software utility designed to give you centralized control of supported gaming products, making it easy to tune the look and feel of your system. From a single intuitive interface, Armoury Crate helps you customize RGB lighting and effects for compatible devices and synchronize them with Aura Sync to create a unified lighting scheme across your system. In addition, Armoury Crate’s Fan Xpert4 tool provides comprehensive control over fans, water pumps and all-in-one (AIO) coolers.
You can also use Armoury Crate to download drivers, software and user manuals, register products, and tap into a special news feed that connects you to the global ASUS gaming community.
*Windows 10 required for full Aura Sync functionality within Armoury Crate. For Windows 8 and earlier versions, standalone Aura Sync software is available for free download from the product support site.
Download Link ›››
- AURA SYNC
- Fan Control
- Device Configuration
- Driver & Manual Download
- Gaming Highlight
- Account Management
AIDA64 Extreme
The ROG Maximus Z690 Formula includes a one-year AIDA64 Extreme subscription. This industry-leading system information tool provides detailed information about installed hardware and software, and it also provides benchmarks for measuring performance of the entire system or individual components. AIDA64 Extreme includes a monitoring and diagnostics feature to detect and prevent hardware issues. All vital system sensors can be tracked in real time, allowing voltage readings, fan speeds, and temperature information to be viewed on the desktop, sent to dedicated displays, or the OLED panels of ROG AIO liquid coolers*.
*Support available for ROG Ryujin II and later models.
Learn More About AIDA64 >
- ROG x AIDA64 Extreme
- Hardware Monitor Display
Graphics Card Holder
Featuring a magnetic base, adjustable slider and hinge, the ROG Graphics Card Holder banishes sag and provides support where it’s needed most.
CUSTOMER REVIEWS
Product added to comparison. Add up to 4 products or proceed to view compare products selected.
