ROG STRIX X870E-E GAMING WIFI

ASUS estore price $499.99
ASUS estore price $499.99
  • Features
  • Tech Specs
  • Awards
  • Gallery
  • Where to buy
  • Support

ROG STRIX X870E-E
gaming wifi

The ROG Strix X870E-E Gaming WiFi is engineered to harness the full potential of AMD Ryzen™ 9000 Series processors. Featuring PCIe® 5.0 support, AI Overclocking, AI Cooling II, AI Networking II, and AEMP, setup is streamlined while performance is maximized. Dual USB4® Type-C ports and WiFi 7 with Realtek 5Gb Ethernet ensure top-tier connectivity, while robust heatsinks keep M.2 drives cool under heavy loads. This motherboard not only meets the demands of gaming and professional applications but also delivers the power and connectivity essential for advanced AI PC applications.


Click to check our X870E/X870 Motherboards Guide

AMD RYZEN logo AMD X870E chipsetlogo Advanced AI PC ready logo 3 MONTH FREE Adobe Creative Cloud
The ROG Strix X870E-E is ready to launch into lightspeed.
  • Cooling
  • Gaming Immersion
  • Connectivity

Extreme Power & Performance

Strix X870E-E performance specifications Strix X870E-E performance specifications
  1. Dual ProCool II Power Connectors
  2. AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
  3. EXPANSION SLOTS

    ・ 1 x PCIe 5.0 x16 SafeSlot [CPU]

    ・ 1 x PCIe 4.0 x16 Slots (x4) [Chipset]

  4. 18(110A)+ 2(110A)+ 2 Power Stages
  5. DDR5 8400+ MT/s (OC)

    ・ 4 x DIMM

    ・ Dual Channel

  6. 5 x M.2 Slots

    ・ 1 x M.2 22110 (PCIe 5.0 x4)

    ・ 2 x M.2 2280 (PCIe 5.0 x4)

    ・ 2 x M.2 2280 (PCIe 4.0 x4)

ASUS AI INTELLIGENCE

  • ai OVERCLOCKING

    ASUS AI Overclocking profiles the CPU and cooling to predict the optimal configuration and push the system to its limits.

    AI Overclocking
  • ai cOOLING II

    Balance the thermals and acoustics of any build with a single click.

    AI COOLING II
  • AI NETWORKING II

    AI Networking II combines intelligent technologies to continuously optimize network performance, provide trustworthy and seamless connectivity, and unleash the full speed of WiFi 7*.

    *Features may vary by model.

    AI NETWORKING II

PerformanceOVERCLOCKING

  • Dynamic OC Switcher

    Lightly-threaded tasks get fantastic uplift using AMD Precision Boost Overdrive (PBO), but all-core frequencies can be pushed higher via traditional overclocking. The Dynamic OC Switcher dynamically engages PBO or your preferred settings based on the CPU current or temperature, giving you the best of both worlds. Core Flex and PBO Enhancement can also be deployed to work in tandem with the Dynamic OC Switcher and further bolster performance on both sides of the aisle.

    Dynamic OC Switcher diagram
  • Core Flex

    Core Flex empowers you to smash limits farther than ever before by letting you control clock, power, and thermals in creative new ways. In its simplest form, you can maximize base clock during lighter loads and set breakpoints to gradually reduce CPU core frequency as temperature or current increases. But the system is extremely adaptable, supporting multiple user-controlled functions that can manipulate power, current, and temperature limits independently so that you can bend CPU performance to your will.

    Core Flex diagram
  • Asynchronous Clock

    For next-level frequency flexibility, the ROG Strix X870E-E features a built-in clock generator that isolates CPU base clock from memory, PCIe, and the Infinity Fabric speed. Drive CPU performance to its absolute brink while maintaining the stability of related clock domains.
    Separate CPU BCLK from other domains for unfettered overclocking

    Asynchronous clock diagram
  • PBO ENHANCEMENT

    AMD Precision Boost Overdrive (PBO) pushes the CPU current and voltage budget to opportunistically increase performance. By aggressively tuning the PBO parameters, AMD's algorithm can leverage the motherboard's robust power solution to ramp up performance even higher.

PerformanceMEMORY

  • DDR5 DOMINATION

    The Strix X870E-E is primed and ready for enthusiast-grade kits courtesy of vast AMD EXtended Profiles for Overclocking (EXPO) support.

    The Strix X870E-E lets you overclock memory up to 8400+ MT/s.
  • NitroPath DRAM Technology

    Frequency up to 400 MT/s higher

    Enhance the slot retention orce by 57%

  • AEMP

    ASUS Enhanced Memory Profile (AEMP) is an exclusive firmware feature for PMIC-restricted memory modules.

    UI interface of AEMP

Power solution

ROG STRIX ULTIMATE POWER DESIGN
18+2+2

The ROG Strix X870E-E features 18+2+2 power stages rated for 110 amps.
  • EIGHT-LAYER PCB
  • 18+2+2 Power Stages

    The VRM features 18+ 2+ 2 power stages, each rated to handle up to 110 amps

    18 Core Power 110A, SPS

    2 GT Power 110A, SPS

    2 AUX Power

  • DUAL PROCOOL II POWER CONNECTORS

    Hi-end chokes and durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards.

  • EIGHT-LAYER PCB

    A multi-layered printed circuit board design quickly dissipates heat around the voltage regulators to improve overall system stability and provide the CPU with more overclocking headroom.

  • ALLOY CHOKES AND DURABLE CAPACITORS

    Hi-end chokes and durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards.

PerformanceCOOLING

  • M.2

    M.2 HEATSINKS, M.2 COMBO-SINK, M.2 BACKPLATE

    Strix X870E-E M.2 heatsinks and backplate layout
  • VRM

    VRM HEATSINK ARRAY

    Strix X870E-E VRM cooling design layout
  • CPU

    CPU FAN HEADERS, AIO PUMP FAN HEADER

    Strix X870E-E fan header locations
  • CHASSIS

    4-PIN FAN HEADERS

    Strix X870E-E chassis fan header locations

leading Connectivity

  • wifi7

    • 320 MHz
    • 6GHz bands
    • 4096 AQM
    • up to4.8X ultra-fast WiFi speeds

    Realtek 5Gb Ethernet

    ASUS WiFi Q-Antenna
  • pcie 5.0

    Fully embracing the new standard, the Strix X870E-E offers end-to-end PCIe 5.0 support.

    The Strix X870E-E PCIe 5.0 M.2 and expansion slot layout
  • USB PORTS

    DUAL USB4 PORTS icon

    DUAL USB4 PORTS

    USB 20Gbps icon

    USB 20Gbps

  • Gaming Audio

    The  Strix X870E-E  motherboard features SupremeFX audio.

EZ PC DIY

  • M.2 Q-Release

  • M.2 Q-Slide

  • New M.2 Q-LATCH

  • PCIE® SLOT Q-RELEASE SLIM

  • Q-Antenna

  • Q-LED

  • START BUTTON

    START BUTTON
  • Q-CODE

    Q-CODE
  • CLEAR CMOS& BIOS FLASHBACK™

    CLEAR CMOS& BIOS FLASHBACK™

BIOS

BIOS Q-DASHBOARD

Simplify your motherboard configuration with BIOS Q-Dashboard. Its intuitive visual representation of hardware connections and corresponding BIOS settings takes the complexity out of setting up your system. Upgrade now, and discover the power of BIOS Q-Dashboard to easily and efficiently enhance your computing setup .

UEFI BIOS

The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans.

UEFI BIOS

SOFTWARE UTILITIES

glide x logo

ASUS GLIDEX

ASUS GlideX is a cross-device, cross-platform screen-sharing, screen-control and operation solution for enhanced productivity across PCs, tablets, and smartphones via USB or WiFi. Features include screen mirroring, screen extension, unified control with one keyboard and mouse, easy file transfers, and using mobile cameras as PC webcams. It's compatible with Windows, macOS, Android, and iOS.


Learn more about GlideX >
  • ASUS GldX fuicionscreenshot

    Mirror

  • ASUS GldX fuicionscreenshot

    Extend(PC to Mibile)

  • ASUS GldX fuicionscreenshot

    Extend(PC to PC)

  • ASUS GldX fuicionscreenshot

    Unify Control

HWiNFO

HWiNFO and ROG have collaborated on this comprehensive system information and diagnostic tool that provides detailed information about hardware components and real-time monitoring of system performance in ROG style. It supports a wide range of hardware devices, and it is regularly updated to include the latest technologies.

HWINFO interface
HWINFO interface

ASUS DRIVER HUB

ASUS DriverHub streamlines the installation and management of ASUS drivers and utilities to keep your hardware up-to-date and performing optimally. This standalone application automatically detects current driver versions and presents available updates in a list view. By default, it supports ASUS motherboards, and users are invited to install ASUS DriverHub after OS installation. Additionally, ASUS DriverHub offers one-click installation and update checks, making it easier for users to keep their systems running smoothly and efficiently.

ASUS DRIVER HUB interface

AIDA64 EXTREME

The ROG Strix X870E-E includes a sixty-day AIDA64 Extreme subscription, a tool that provides detailed information about hardware and software, as well as benchmarks to measure the performance of the entire system or individual components. AIDA64 Extreme includes a monitoring and diagnostics feature to detect and prevent hardware issues. All vital system sensors can be tracked in real time, allowing voltage readings, fan speeds, and temperature information to be displayed on the desktop or sent to dedicated displays or to the LCD panels of ROG AIO liquid coolers*.
*Support available for ROG Ryujin II and later models.

AIDA64 EXTREME interface

ARMOURY CRATE

Armoury Crate is a software utility designed to give you centralized control of supported gaming products, making it easy to tune the look and feel of your system. From a single intuitive interface, Armoury Crate helps you customize RGB lighting and effects for compatible devices and synchronize them with Aura Sync to create a unified lighting scheme across your system. In addition, Armoury Crate’s Fan Xpert4 tool provides comprehensive control over fans, water pumps, and all-in-one (AIO) coolers.

ARMOURY CRATE interface

PLAY IN STYLE

UNDENIABLY ROG STRIX

Diagonal slats, brushed aluminum, and bold RGB have become hallmarks of the ROG aesthetic, and the Strix X870E-E bears all of them with pride. But for this generation, translucent diffusers line the I/O shroud and the Q-Release array, softly contrasting the metallic heatsinks nearby.

  • PHOTO
  • VIDEO
The Strix X870E-E front and back

ROG Strix Z790-A Gaming WiFi

OUTSHINE THE COMPETITION

ROG Strix motherboards feature ASUS Aura technology, enabling full lighting control and a variety of presets for both onboard RGB LEDs and third-party accessories. Effects can be easily synced across compatible ROG graphics cards, monitors, keyboards, and mice to give your setup a unified look.


Learn more about Aura Sync >
Interactive Aura Sync demo

ADDRESSABLE GEN 2 RGB HEADERS

The ROG Strix X870E-E features onboard Gen 2 RGB headers that automatically optimize lighting effects for the number of LEDs present in compatible ARGB gear. The headers are also fully backwards compatible with Gen 1 RGB devices, giving you flexibility to light up as you choose.

Strix X870E-E RGB header locations

COOLER COMPATIBILITY

ASUS AIO coolers offer robust performance, high overclocking potential, bold aesthetics and customizable functionality for X870 motherboards, empowering you to build your dream gaming rig.

Strix X870E-E is with ROG Strix LC III 360 ARGB LCD

THE ROG STRIX
ECOSYSTEM AWAITS

Level up your game with ROG Strix. Enjoy complimentary aesthetics, control, and compatibility across AIO coolers, cases, peripherals, and much more. ROG offers more choices than any other brand.

ROG gaming setup with peripherals, monitor, and gaming PC
“AMD Ryzen™ processors “AMD Ryzen™ processors

BUILD FOR THE MOST ADVANCED PC FOR GAMING AND CREATING

When only the fastest will do, a Strix X870E/X870 motherboard delivers. With USB 4.0 onboard along with robust overclocking¹ capabilities, featuring faster dual-channel DDR5 memory support, AMD EXPO™ technology and PCIe® 5.0 support for both graphics and NVMe, you can play the most demanding games and deliver your biggest projects with the revolutionary performance of an AMD X800-series motherboard and AMD Ryzen™ 9000, 8000, and 7000 Series processors.


  • 1. Overclocking and/or undervolting AMD processors and memory, including without limitation, altering clock frequencies / multipliers or memory timing / voltage, to operate outside of AMD’s published specifications will void any applicable AMD product warranty, even when enabled via AMD hardware and/or software. This may also void warranties offered by the system manufacturer or retailer. Users assume all risks and liabilities that may arise out of overclocking and/or undervolting AMD processors, including, without limitation, failure of or damage to hardware, reduced system performance and/or data loss, corruption or vulnerability. GD-106.
  • © 2024 Advanced Micro Devices, Inc. All rights reserved. AMD, the AMD Arrow logo, Radeon, Ryzen and combinations thereof are trademarks of Advanced Micro Devices, Inc. Other product names used in this publication are for identification purposes only and may be trademarks of their respective owners.
A tree with the ROG logo in the background A tree with the ROG logo in the background

Dare to Be Green

We at the Republic of Gamers are on a mission to create a sustainable future where all gamers can flourish on the planet we call home.

Every step counts, and as part of ROG’s commitment to creating a more sustainable future, ROG has begun to utilize post-consumer recycled (PCR)
