M.2 Heatsink
Keeps the M.2 SSD at the optimum operating temperature for consistent performance and reliability
M.2 Backplate
Provides additional mass to deal with the thermal load of high-performance M.2 drives
POWER DESIGN
Digital power control and an array of power stages provide the muscle needed to control the latest Intel CPUs.
Teamed Power Stages
14+2 power stages combine high-side and low-side MOSFETS and drivers into a single package, delivering the power and efficiency that the latest Intel processors demand.
Alloy Chokes and Capacitors
Superior chokes and durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards.
ProCool II
Power Connector
The ASUS ProCool II socket is built to tight specifications to ensure flush contact with the PSU power lines. Metal armor improves heat dissipation, and lower impedance helps prevent hotspots and improves reliability.
Digi+
Power Control
The built-in Digi+ voltage-regulator module (VRM) is one of the finest in the industry, ensuring ultra-smooth and clean power delivery to the CPU.
Six-Layer PCB
The PCB design quickly dissipates heat around the VRM to improve overall system stability and provide the CPU with more overclocking headroom.
- Cooling Innovation
- Cooler By Design
Cooling Innovation
-
Integrated I/O Cover and VRM Heatsinks
Two VRM heatsinks and an aluminum I/O cover provide ample mass and surface area to deal with the heat generated by the latest Intel processors.
-
Thermal Pads
High-quality thermal pads efficiently transfer heat from the inductor and phase array to the heatsink.
-
M.2 Heatsinks
The M.2 heatsinks keep the M.2 SSD at optimum operating temperature for consistent performance and reliability.
-
M.2 Backplate
An integrated M.2 backplate helps ensure that high-performance drives deliver peak performance, even when airflow is restricted.
Cooler by Design
ROG Strix Z590 motherboards feature comprehensive cooling options that are configurable via Fan Xpert 4 or the UEFI BIOS.
- CPU
- M.2
- Chassis
CPU Fan Header
A dedicated pair of PWM/DC fan headers for CPU coolers
AIO Pump Fan Header
A dedicated PWM/DC header for self-contained water-cooling setups
4-Pin PWM/DC Fan Headers
Each header supports auto-detection of PWM or DC fans
*Supports ASUS HYDRANODE
Hover or focus to see M.2 backplate underneath
- Two-Way AI Noise Cancelation
- AI Overclocking
- AI Cooling
- AI Networking
Two-Way AI Noise Cancelation
This powerful ASUS-exclusive utility leverages a massive deep-learning database to reduce background noise from the microphone* and incoming audio while preserving voices. Distracting keyboard clatter, mouse clicks and other ambient noises are removed so you can hear and be heard with perfect clarity while gaming or during calls.
*A splitter cable is necessary when using a 3.5 mm headset.
-
500M
Deep-learning Database
-
Audio
Input/output
-
High
Fidelity
-
Minimal
Performance Impact
COD: MW - FPS (2560 x 1440)
ASUS Two-Way
AI Noise Cancelation
Similar technology
Minimal
performance impact
*Actual performance varies by configuration
Hear the difference
-
TALKING
-
HEARING
without noise
ASUS Motherboard User -
HEARING
without noise
-
TALKING
Other Party
- Background noise
- Other human voice
- Human speech
AI Overclocking
ROG AI Overclocking is an intelligent utility that helps you get the most out of your build by automatically profiling your CPU and cooling system to predict optimal voltage and frequency settings.
Accessible via the AI Suite software in Windows or directly through the UEFI, the intuitive AI Overclocking user interface enables users of all levels. A range of customizable settings are available for seasoned overclockers, and an auto-tuning option is available for beginners.
AI OVERCLOCKING AT A GLANCE
-
Designed by Experts
At the heart of AI Overclocking is a proprietary algorithm developed by ROG R&D engineers who worked with world-renowned overclockers to create a tool for users of all levels.
-
Predictive Edge
The algorithm analyzes your CPU and cooling system and, based on what it finds, predicts optimal settings. The software then automatically applies these settings to guide the clocking process, balancing frequency and voltage.
-
Real-time Adjustments
Workload, system temperature, fan speed and power draw are automatically monitored by the software, and the information is used to make real-time adjustments to ensure ongoing optimal performance.
AI Overclocking Guide
The AI Overclocking Guide provides detailed information and instructions about how to tune your system manually. It can be accessed by hitting the F11 hotkey.
Core Group Loading
For the high-core-count processors in the Z590 series, AI Overclocking software lists data according to core group. This gives you adaptive control based on the status of core groups, and it provides target frequency and voltage estimations needed for manual tuning.
AI Overclocking in AI Suite
Onboard intelligence lets you automate overclocking with full, flexible control via 5-Way Optimization within AI Suite (in Windows).
AI Cooling
ASUS AI Cooling technology automatically manages and controls motherboard-connected fans to ensure optimal settings based on current system load and temperature.
Self-Adaptive Fan Tuning
-
CPU temperature detection
AI Cooling detects CPU temperatures and uses a proprietary algorithm to calculate the lowest fan speed required to effectively cool the system and keep fan noise down.
-
Automated optimization
Under stable system loads, the software automatically lowers fan* speed to the optimal setting, decreasing fan noise without compromising performance.
*Fans need to be connected to the following headers for AI Cooling control: CPU_FAN / CPU_OPT / CHA_FAN / M.2_FAN / H_AMP / RAD_FAN -
Ongoing monitoring
AI Cooling continues to monitor the system and adjust fan speed based on current load.
- Automatic Tuning
- Manual Tuning
One-Click Activation
AI Cooling can easily be activated via the Fan Xpert 4 dashboard in ASUS AI Suite 3. Once activated, it will override all manual controls.
Fan speed references
For those who prefer manual control, AI Cooling provides reference points on a graph, detailing fan speed in relation to temperature to provide a guide for fan settings.
AI Networking
The proprietary ROG GameFirst VI utility is designed to help all users — beginners, experts, and everyone in between — optimize network settings to ensure smooth online gameplay. New to this generation, GameFirst VI features AI-enhanced identification and boost technologies to ensure faster and smarter network optimization.
HOW IT WORKS
-
Identification
GameFirst VI analyzes usage patterns and the digital signatures of your applications and compares them to a database of over 200,000 apps.
-
Boost
GameFirst VI intelligently switches application priority and adjusts bandwidth, depending on the situation. When gaming, it accelerates and prioritizes game packets to give you supersmooth online gameplay ― even when you're streaming high-quality video or transferring large files.
-
Visualization
An intuitive graph provides an overview of real-time network status. Simply click on the tab to view the current bandwidth usage of each application, geolocation status of each network connection, or an analysis of the WiFi channels.
WHAT IT DOES
ADAPTIVE INTELLIGENCE
GameFirst VI notes what you're currently doing and adjusts bandwidth accordingly to ensure smooth online experiences, even when multitasking.
GAMING FIRST MODE
Gaming First mode leverages a massive application database and an analysis of your frequently used apps to prioritize gaming network traffic. This reduces jitter and decreases ping to give you lag-free online gaming.
Network Insight
WIFI Quick Assist analyzes network information and generates a graph to give you a clear picture of current network status. In addition, when paired with an ROG router, you can scan your WiFi network to find the best channel and use Game Boost to prioritize gaming devices and packets.
